Anti-ATP5A antibody [EPR13030(B)] (Alexa Fluor® 647)

• Supplier: Abcam
• Catalog: ab196198
• Prices: $431.00
• Sizes: 100 µl
• Host: Rabbit
• Clonality: Monoclonal
• Isotype: IgG
• Clone: EPR13030(B)
• Applications: ICC/IF ICC/IF FC
• Species Reactivities: Human, Mouse, Rat
• Antigen: Synthetic peptide (the amino acid sequence is considered to be commercially sensitive) within Human ATP5A aa 200-300 (Cysteine residue)
• Description: Rabbit Monoclonal
• Gene: ATP5A1
• Conjugate: Alexa Fluor® 647

Product images

Overlay histogram showing HeLa cells stained with ab196198 (red line). The cells were fixed with 80% methanol (5 min) and then permeabilized with 0.1% PBS-Tween for 20 min. The cells were then incubated in 1x PBS / 10% normal goat serum / 0.3M glycine to block non-specific protein-protein interactions followed by the antibody (ab196198, 1/50 dilution) for 30 min at 22°C. Isotype control antibody (black line) was rabbit IgG (monoclonal) Alexa Fluor® 647 used at the same concentration and conditions as the primary antibody. Unlabelled sample (blue line) was also used as a control.Acquisition of >5,000 events were collected using a solid-state 25mW red diode laser (635 nm) and 675/30 bandpass filter.This antibody gave a positive signal in HeLa fixed with 4% formaldehyde (10 min)/permeabilized with 0.1% PBS-Tween for 20 min used under the same conditions.

ab196198 staining ATP5A in HeLa cells. The cells were fixed with 100% methanol (5 min), permeabilized in 0.1% Triton X-100 for 5 minutes and then blocked in 1% BSA/10% normal goat serum/0.3M glycine in 0.1%PBS-Tween for 1h. The cells were then incubated with ab196198 at 1/100 dilution (shown in red) and ab195887, Mouse monoclonal [DM1A] to alpha Tubulin (Alexa Fluor® 488, shown in green) at 2µg/ml overnight at +4°C. Nuclear DNA was labelled in blue with DAPI.Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).
