All lanes : Anti-KCNJ5 antibody (ab113699) at 1 µg/mlLane 1 : Testis (Human) Tissue Lysate - adult normal tissue (ab30257)Lane 2 : A498 (Human Kidney Carcinoma) Whole Cell LysateLane 3 : MCF7 (Human breast adenocarcinoma cell line) Whole Cell LysateLane 4 : A549 (Human lung adenocarcinoma epithelial cell line) Whole Cell LysateLysates/proteins at 10 µg per lane.SecondaryGoat Anti-Rabbit IgG H&L (HRP) preadsorbed (ab97080) at 1/5000 dilutiondeveloped using the ECL techniquePerformed under reducing conditions.
IHC image of KCNJ5 staining in human pancreas formalin fixed paraffin embedded tissue section, performed on a Leica BondTM system using the standard protocol F. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20 mins. The section was then incubated with ab113699, 1µg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX. For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.
