All lanes : Anti-AIF antibody (ab87307) at 1/250 dilutionLane 1 : K562 (Human erythromyeloblastoid leukemia cell line) Whole Cell LysateLane 2 : Liver (Human) Tissue Lysate - adult normal tissue (ab29889)Lane 3 : Jurkat (Human T cell lymphoblast-like cell line) Whole Cell LysateLane 4 : HepG2 (Human hepatocellular liver carcinoma cell line) Whole Cell LysateLysates/proteins at 10 µg per lane.SecondaryGoat polyclonal to Rabbit IgG - H&L - Pre-Adsorbed (HRP) at 1/3000 dilutiondeveloped using the ECL techniquePerformed under reducing conditions.
ICC/IF image of ab87307 stained HepG2 cells. The cells were 4% formaldehyde fixed (10 min) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody ab87307 at 5µg/ml overnight at +4°C. The secondary antibody (green) was Alexa Fluor® 488 goat anti- rabbit IgG (H+L) used at a 1/1000 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43µM.
