Anti-Cathepsin D antibody [4G2]
| Name | Anti-Cathepsin D antibody [4G2] |
|---|---|
| Supplier | Abcam |
| Catalog | ab40697 |
| Prices | $398.00 |
| Sizes | 100 µl |
| Host | Mouse |
| Clonality | Monoclonal |
| Isotype | IgG2b |
| Clone | 4G2 |
| Applications | ELISA WB FC |
| Species Reactivities | Human |
| Antigen | Recombinant fragment, corresponding to amino acids 21-412 of Human Cathepsin D |
| Description | Mouse Monoclonal |
| Gene | CTSD |
| Conjugate | Unconjugated |
| Supplier Page | Shop |
Product images
![Overlay histogram showing MCF7 cells stained with ab40697 (red line). The cells were fixed with 80% methanol (5 min) and then permeabilized with 0.1% PBS-Tween for 20 min. The cells were then incubated in 1x PBS / 10% normal goat serum / 0.3M glycine to block non-specific protein-protein interactions followed by the antibody (ab40697, 1μg/1x106 cells) for 30 min at 22°C. The secondary antibody used was Alexa Fluor® 488 goat anti-mouse IgG (H+L) (ab150113) at 1/2000 dilution for 30 min at 22°C. Isotype control antibody (black line) was mouse IgG2b [PLPV219] (ab91366, 1μg/1x106 cells) used under the same conditions. Unlabelled sample (blue line) was also used as a control. Acquisition of >5,000 events were collected using a 20mW Argon ion laser (488nm) and 525/30 bandpass filter.](http://www.bioprodhub.com/system/product_images/ab_products/2/sub_1/21570_ab40697-5-ab40697FC.jpg)
Overlay histogram showing MCF7 cells stained with ab40697 (red line). The cells were fixed with 80% methanol (5 min) and then permeabilized with 0.1% PBS-Tween for 20 min. The cells were then incubated in 1x PBS / 10% normal goat serum / 0.3M glycine to block non-specific protein-protein interactions followed by the antibody (ab40697, 1μg/1x106 cells) for 30 min at 22°C. The secondary antibody used was Alexa Fluor® 488 goat anti-mouse IgG (H+L) (ab150113) at 1/2000 dilution for 30 min at 22°C. Isotype control antibody (black line) was mouse IgG2b [PLPV219] (ab91366, 1μg/1x106 cells) used under the same conditions. Unlabelled sample (blue line) was also used as a control. Acquisition of >5,000 events were collected using a 20mW Argon ion laser (488nm) and 525/30 bandpass filter.
![All lanes : Anti-Cathepsin D antibody [4G2] (ab40697) at 1/1000 dilutionLane 1 : HepG2 cell lysateLane 2 : Hep3B cell lysateLane 3 : MDA-MB-231 cell lysateLane 4 : MCF7 cell lysateLysates/proteins at 20 µg per lane.developed using the ECL techniqueObserved band size : 45 kDa (why is the actual band size different from the predicted?)](http://www.bioprodhub.com/system/product_images/ab_products/2/sub_1/21571_40697_1.jpg)
All lanes : Anti-Cathepsin D antibody [4G2] (ab40697) at 1/1000 dilutionLane 1 : HepG2 cell lysateLane 2 : Hep3B cell lysateLane 3 : MDA-MB-231 cell lysateLane 4 : MCF7 cell lysateLysates/proteins at 20 µg per lane.developed using the ECL techniqueObserved band size : 45 kDa (why is the actual band size different from the predicted?)
developed using the ECL techniquePerformed under reducing conditions.Exposure time : 30 seconds
Product References
Ambroxol improves lysosomal biochemistry in glucocerebrosidase mutation-linked - Ambroxol improves lysosomal biochemistry in glucocerebrosidase mutation-linked
McNeill A, Magalhaes J, Shen C, Chau KY, Hughes D, Mehta A, Foltynie T, Cooper JM, Abramov AY, Gegg M, Schapira AH. Brain. 2014 May;137(Pt 5):1481-95.
Global profiling of proteolytically modified proteins in human metastatic - Global profiling of proteolytically modified proteins in human metastatic
Shen C, Yu Y, Li H, Yan G, Liu M, Shen H, Yang P. Proteomics. 2012 Jun;12(12):1917-27.
Synaptic protein expression is regulated by a pro-oxidant diet in APPxPS1 mice. - Synaptic protein expression is regulated by a pro-oxidant diet in APPxPS1 mice.
Broadstock M, Lewinsky R, Jones EL, Mitchelmore C, Howlett DR, Francis PT. J Neural Transm. 2012 Apr;119(4):493-6.
FKBPL regulates estrogen receptor signaling and determines response to endocrine - FKBPL regulates estrogen receptor signaling and determines response to endocrine
McKeen HD, Byrne C, Jithesh PV, Donley C, Valentine A, Yakkundi A, O'Rourke M, Swanton C, McCarthy HO, Hirst DG, Robson T. Cancer Res. 2010 Feb 1;70(3):1090-100.
